Zulu Frames
$399.00
Unit price
/
Unavailable
SPEC | ZULU THREE | ZULU FOUR | ZULU FIVE |
---|---|---|---|
Wheel Diameter | 20 in | 24 in | 26 in |
Seat Tube Angle | 74° | 74° | 74° |
Effective Top Tube Length | 17.4 in / 445 mm | 19.7 in / 500 mm | 20.9 in / 530 mm |
Stack | 18.2 in / 448 mm | 21.3 in / 541 mm | 23.1 in / 559 mm |
Seat Tube Length | 10.0 in / 260 mm | 12.2 in / 310 mm | 13.4 in / 350 mm |
Bottom Bracket Drop | 0.6 in / 25 mm | 1.2 in / 45 mm | 1.4 in / 45 mm |
Weight | 1410 grams | 1635 grams | 1700 grams |
Compatible Fork | 80mm travel 380mm axle-crown | 100mm travel 450mm axle-crown | 100mm travel 469mm axle-crown |
Max Tire Size | 20x2.2" | 24x2.3" | 26x2.4" |
Max Chainring Size | 30t | 30t | 30t |
Headset Size | Integrated 1 1/8" IS42/28.6 IS42/30 | Integrated 1 1/8" IS42/28.6 IS42/30 | Integrated 1 1/8" IS42/28.6 IS42/30 |
Rear Axle | 12x142 thru axle (included) | 12x142 thru axle (included) | 12x142 thru axle (included) |
Rear brake rotor | 140mm | 140mm | 140mm |
Bottom Bracket Standard | BSA Threaded 73mm | BSA Threaded 73mm | BSA Threaded 73mm |
Seat tube internal diameter | 31.6mm | 31.6mm | 31.6mm |
